Reference : TE-130 - Liquid Heating Engineering Training System

The TE-130 training system is designed for the study of heat transfer processes in liquids for university laboratories, engineering education, and technical training centers. The equipment enables students and researchers to perform practical experiments related to thermal and fluid dynamics processes using real-time measurements and data analysis.

Educational Applications and Laboratory Experiments

The system allows the following laboratory studies and practical experiments:

• Determination of the heat capacity of a liquid by heating a flowing liquid stream.
• Determination of liquid viscosity at different temperatures according to laminar flow theory.
• Determination of the heat transfer coefficient during fluid flow inside a pipe.
• Analysis of the transferred thermal power in a “pipe-in-pipe” heat exchanger according to different heat carrier flow arrangements.
• Determination of the transferred thermal power of a shell-and-tube heat exchanger.
• Study of the characteristics of an air-to-water or air-to-air heat exchanger.

Technical Specifications

• Robust metal structure with aluminum frame.
• Integrated electric water heater.
• Plate heat exchanger.
• “Pipe-in-pipe” heat exchanger.
• Air-to-water or air heat exchanger.
• Circulation pumps.
• Water tanks.
• Integrated sensors and flow meters.
• Connecting pipes, hoses, and valves.
• Specialized software for data acquisition and processing on a laptop computer.
• Software interface available in English and/or Russian.
• All markings, nameplates, and equipment labels are provided in English and/or other langage

Reference : FCT-693

The Fuel Cell Trainer is a comprehensive educational system designed to teach the fundamental engineering principles of PEM fuel cell technology. With extensive experimental capabilities and thoroughly revised instructional materials, including predefined experiments, it provides a complete and structured learning solution.

All components of the fuel cell system are individually displayed, ensuring maximum transparency and clarity during instruction. Integrated parameter displays allow real-time monitoring of operating conditions, enhancing both theoretical understanding and practical insight.

Thanks to its modular design, the Fuel Cell Trainer can be easily adapted to different educational levels, from introductory courses to advanced engineering programs. The system is suitable for users with limited prior experience. The included software supports computer-assisted measurement, data acquisition, and experimentation, enabling precise analysis and documentation of results.

Key Features

• Redesigned system architecture for enhanced engineering education
• USB interface for simple plug-and-play installation
• Improved instructional materials for both instructors and students
• Advanced experimentation software with integrated data acquisition
• Quick-start guides for fast setup and efficient operation

Learning Objectives

• Understanding the structure and operating principles of PEM fuel cell systems
• Application of thermodynamic fundamentals
• Analysis of characteristic curves and efficiency performance
• Fundamentals of system integration and power electronics

Areas of Application

Suitable for lectures and practical training in:

• Electrical Engineering
• Energy Engineering
• Process Engineering
• Mechanical Engineering
• Automotive Engineering

References :

• SHE-811 Solar Hydrogen Extension 30 nl/h
• SHE-812 Solar Hydrogen Extension 72 nl/h

The Solar Hydrogen Trainer is a 400 Wp off-grid photovoltaic system combined with an electrolyzer for on-site hydrogen production. Using clean solar energy, the system generates hydrogen sustainably and can be integrated with the Fuel Cell Trainer or the Nexa® Training System to form a comprehensive micro-laboratory platform.

The system enables complete energy balancing of the solar hydrogen generation process. Performance and production data from the PV modules, power electronics, battery storage, and electrolyzer are displayed in the included software and can be logged and exported for further analysis. Energy flows between individual components are clearly visualized, providing full system transparency.

Mobile solar modules with adjustable tilt angles and optional solar sensors allow for advanced experimentation in photovoltaic performance and system optimization.

Key Features

• Fundamentals of solar photovoltaic power generation
• Operating principles of off-grid solar systems
• Efficiency analysis of solar hydrogen production
• System dimensioning of solar hydrogen applications
• Dedicated focus on Power-to-Gas training concepts

Sample Experiments

• Optimization of solar module alignment
• Determination of electrolyzer efficiency
• Performance analysis and behavior of photovoltaic modules

Reference : 8021637

Technical Features

• 16 digital inputs/outputs
• 4 analog inputs and 2 analog outputs
• 8 digital inputs/outputs each wired to a 24-pin SysLink connector (IEEE 488 compliant)
• Digital input 0 on Port 1 and Port 2 configurable as high-speed counter input
• Counter inputs operable with voltage levels from 5 to 24 V DC
• Analog I/O connected via a 15-pin Sub-D connector
• 12-bit analog-to-digital conversion resolution
• Sampling rate: 0.5 kHz
• Data communication via RS232 serial interface or USB
• Transmission rate: 115.2 kbaud

Up to four EasyPort USB modules can be connected simultaneously via a USB hub or four separate USB ports on a PC. Each module must be assigned a unique address.

For signal exchange between EasyPort USB and PC software, the EzOPC OPC server or the EasyPort USB ActiveX control component is available.

Reference : HS-105

Reference : 548687

Technical Features

• 16 digital inputs/outputs
• 4 analog inputs and 2 analog outputs
• 8 digital inputs/outputs each wired to a 24-pin SysLink connector (IEEE 488 compliant)
• Digital input 0 on Port 1 and Port 2 configurable as high-speed counter input
• Counter inputs operable with voltage levels from 5 to 24 V DC
• Analog I/O connected via a 15-pin Sub-D connector
• 12-bit analog-to-digital conversion resolution
• Sampling rate: 0.5 kHz
• Data communication via RS232 serial interface or USB
• Transmission rate: 115.2 kbaud

Up to four EasyPort USB modules can be connected simultaneously via a USB hub or four separate USB ports on a PC. Each module must be assigned a unique address.

For signal exchange between EasyPort USB and PC software, the EzOPC OPC server or the EasyPort USB ActiveX control component is available.

References

SAS1000 Solar array software for IT6500C/IT6000B/IT6000C/IT-M3600

SAS1000L Solar array software for IT6500C/IT6000B/IT6000C/IT-M3600 (power ≤15kW)

SAS1000M Solar array software for IT6500C/IT6000B/IT6000C/IT-M3600 (multi-channel)

ITECH introduces its latest high-speed, high-performance photovoltaic simulation solution. When combined with high-power DC power supplies, the SAS1000/L solar array simulation software accurately reproduces solar array I-V curves, with output voltage up to 2250 V and scalable system power up to 10 MW.

The system delivers fast dynamic response, excellent control accuracy, high repeatability, outstanding stability, and precision performance. It features built-in simulation models compliant with EN 50530, Sandia National Laboratories PV model, NB/T 32004, CGC/GF004, and CGC/GF035.

Users can easily configure test regulations, material types, Vmp, Pmp, and other parameters to simulate I-V curve characteristics and automatically generate test reports. The software is ideal for static and dynamic maximum power point tracking (MPPT) performance testing of photovoltaic inverters.

Product Features

• Automatic wide-range output, with voltage up to 2250 V
• Scalable power up to 10 MW
• Built-in I-V curve mathematical model for accurate solar array simulation
• Simulation of various solar cell technologies (monocrystalline, polycrystalline, thin-film), including Fill Factor configuration
• I-V curve simulation under varying temperature and irradiation conditions
• Shading simulation for solar panels (e.g., cloud or tree shadow scenarios)
• Static and dynamic MPPT efficiency testing
• Built-in EN 50530, Sandia National Laboratories PV model, NB/T 32004, CGC/GF004, and CGC/GF035 test programs with automatic report generation
• Graphical user interface with real-time MPPT status monitoring
• Automatic programming of up to 100 I-V curves via Voc, Isc, FF, Pm, and other parameter points
• Support for 100 × 128-point curves and 4096-point high-resolution programming
• Adjustable output impedance
• Independent edge configuration for multiple operating modes, with adjustable rise and fall times
• Seamless bidirectional current switching for rapid cell charge and discharge simulation/li>
• Built-in DIN 40839 and ISO 16750-2 compliance
• Standard USB, RS232, GPIB, and LAN (LXI compliant) interfaces
• Support for up to 20 solar power supplies for multi-channel MPPT testing

Applications

• Design and validation of PV inverter MPPT circuits and algorithms
• Verification of inverter MPP voltage range and full-load MPP voltage range/li>
• Validation of static maximum power tracking efficiency
• Dynamic MPPT performance testing according to EN 50530, Sandia National Laboratories PV model, NB/T 32004, CGC/GF004, and CGC/GF035
• Verification of inverter start-up voltage, maximum input voltage, maximum input current, and related electrical parameters
• MPPT validation under partial shading conditions
• DC terminal protection testing (OVP, OPP)
• Validation of microgrid control centers and photovoltaic energy storage control functions
• MPPT performance verification from sunrise to sunset operating conditions
• Total and conversion efficiency testing of inverters when used with the IT9100 power analyzer
