SFG-1000 Series - 3 MHz Function Generator
References
- SFG-1003 : Function Generator, 0,1 Hz to 3 MHz
- SFG-1013 : Function Generator, 0,1 Hz to 3 MHz, dual display
Overview
This DDS (Direct Digital Synthesis) based function generator provides a reliable, accurate, and cost-effective solution for signal generation in educational, laboratory, and industrial environments. Built on an advanced FPGA architecture, it ensures high stability and precision while maintaining ease of use.
With a frequency range from 0.1 Hz to 3 MHz and fine resolution, this device is ideal for applications requiring accurate signal generation without unnecessary complexity.
Key Features
- DDS technology with FPGA design
- Frequency range: 0.1 Hz to 3 MHz
- Frequency resolution: 100 mHz
- Frequency accuracy: ± 20 ppm
- Frequency stability: ± 20 ppm
- Low distortion: -55 dBc (0.1 Hz to 200 kHz)
- Voltage display (SFG-1013)
- Multiple outputs: analog and TTL
Waveform Types
- Sine
- Square
- Triangle
- TTL output
Applications
- Automatic control training
- Vibration testing
- Electronic device testing and adjustment
- Circuit validation and troubleshooting
- Laboratory experiments
Key Advantages
- High signal stability and accuracy
- Low distortion for reliable measurements
- User-friendly interface
- Cost-effective solution
- Versatile for educational and technical use
Signal Performance
Stability and Accuracy
The generator incorporates PLL (Phase-Locked Loop) technology to ensure excellent frequency stability and accuracy across the entire frequency range, minimizing drift and ensuring reliable measurements.
Low Distortion
Using high-performance DACs and fast comparators, the device produces clean signals with very low harmonic distortion, making it suitable for precision testing applications.
Adjustment Functions
- Precise frequency adjustment
- Amplitude adjustment: typically from 2 mVpp to 10 Vpp (into 50 Ohm load)
- Adjustable DC offset: ± 5 V (into 50 Ohm load)
- Signal attenuation: up to 40 dB
- Output ON/OFF control
User Interface
The user interface is designed for simplicity and efficiency, allowing quick access to essential functions. Users can easily configure parameters without extensive training.
