DW-ADQ Series – Multi-Manifold Rotary Evaporator
Reference
- DW-5000ADQ : Multi-Manifold Rotary Evaporator
General Description:
The DW-DQ series is a new generation of rotary evaporators developed by our company, capable of simultaneously concentrating up to 5 samples.
Featuring a compact and elegant design, this device offers ease of use, precise temperature control, reliability, ergonomic operation, and long-lasting durability.
The DW-DQ series rotary evaporator (available in 5 × 50 ml, 5 × 100 ml, or 5 × 150 ml configurations) includes the following features:
Technical Features:
- Large LCD screen with menu interface displaying multiple parameters; rotary knob for easy operation.
- Heating bath with Teflon coating, easy to clean, corrosion-resistant, and high-temperature resistant.
- Maximum temperature up to 99 °C with automatic shut-off in case of overheating.
- Special flask removal system for easy disassembly of the evaporation flask.
- Sealing made of imported PTFE with advanced technology.
- Dual control modes: touchscreen and button-operated automatic lift for safe and convenient use.
- 70 W DC motor ensuring smooth and stable start-up.
- Vertical condenser with drip point design to prevent backflow.
- Intermittent clockwise/counterclockwise rotation with timer function for drying, maximum speed up to 310 rpm.
- Vacuum control via vacuum gauge and vacuum valve to prevent pump oil backflow and improve experiment success rate.
- Heating bath with insulated handle to prevent burns; optimized volume for fast heating.
- Protective cover for heat preservation, energy saving, and spill/boil-over prevention.
Technical Specifications:
- Rotation Speed: 0 – 310 rpm (LCD display)
- Evaporation Capacity: max. 43 ml/min (H₂O)
- Temperature Range / Accuracy: PID control; ambient to 99 °C ± 0.5 °C
- Bath Material: Integral Teflon heating bath with safety handle
- Bath Dimensions: Ø 29 × 17 cm
- Intermittent Rotation: Programmable (0 – 60 s) for powder sample drying
- Lift System: Automatic balanced lift (controlled by screen or button), travel 150 mm, fixed safety distance 60 mm
- Temperature Setting: Rotary knob with LCD display
- Safety: Dry-run protection, programmable automatic stop (0 – 999 min), alarm and standby in abnormal or over-temperature conditions
- Heater Power: 1.5 kW
- Flask Volume: 5 × 150 ml (compatible 0.25 – 5 L)
- Sealing: Imported PTFE with composite anti-corrosion technology
- Condenser: Vertical triple-coil condenser with large surface area and backflow prevention
- Condensation Area: 0.31 m²
- Operating Temperature: 5 °C – 40 °C
Standard Configuration:
- 5 × eggplant-shaped evaporation flasks 150 ml (24#)
- 1 × set of heated flasks (29#)
- 1 × 3 L receiving flask (S35)
Power Supply & Dimensions:
- Power Supply: AC 220 V / 50 Hz
- Product Dimensions: 74 × 44 × 96 cm
- Packaging Dimensions: 78 × 69 × 85 cm
- Gross Weight: 42 kg
